| 電壓 | 400V 系列 | ||||||
| 400V 系列 |
適配電動機功率(開) | 制動單元 | 制動電阻 | ||||
| 型號 | 數量 | 型號 | 數量 | 總功率(KW) | 總電阻 ( Ω ) |
||
| 11 | BU22-4C | 1 | DBH011 | 1 | 1.4 | 40 | |
| 15 | 1 | DBH015 | 1 | 1.5 | 34 | ||
| 18.5 | 1 | DBH18.5 | 1 | 2.0 | 27 | ||
| 22 | 1 | DBH022 | 1 | 2.0 | 27 | ||
| 30 | BU37-4C | 1 | DBH030-4B | 1 | 3.6 | 15 | |
| 37 | 1 | DBH037-4B | 1 | 4.8 | 12 | ||
| 45 | BU55-4C | 1 | DBH045-4B | 1 | 6.0 | 10 | |
| 55 | 1 | DBH055-4B | 1 | 7.2 | 7.5 | ||
| 75 | BU75-4C | 1 | DBH037-4B | 2 | 9.6 | 6.0 | |
| 90 | BU90-4C | 1 | DBH045-4B | 2 | 12.0 | 5.0 | |
| 110 | BU110-4C | 1 | DBH055-4B | 2 | 14.4 | 3.75 | |
| 132 | BU132-4C | 1 | DBH045-4B | 3 | 18.0 | 3.33 | |
| 160 | BU160-4C | 1 | DBH037-4B | 4 | 19.2 | 3.0 | |
| 200 | BU200-4C | 1 | DBH045-4B | 4 | 24.0 | 2.5 | |
| 220 | BU220-4C | 1 | DBH055-4B | 4 | 28.8 | 1.88 | |
| 280 | BU280-4C | 1 | DBH045-4B | 6 | 36.0 | 1.67 | |
