| 伺服電機型號 | Servo Motor Model | LH | LH060H02*1* | LH060H04*1* |
| 額定輸出功率 | Reted Output Power | W | 200 | 400 |
| 額定轉矩 | Rated Torque | N.M | 0.64 | 1.27 |
| 瞬間最大轉矩 | Instantantous | N.M | 1.91 | 3.82 |
| 額定電流 | Rated Current | Arms | 1.3 | 2.7 |
| 瞬間最大電流 | Instantantous Max Current | Arms | 3.9 | 8.1 |
| 額定轉速 | Rated Speed | r/min | 3000 | |
| 最高轉速 | Max.Speed | r/min | 4500 | |
| 轉子轉動慣量 | Rotor Moment Of Inertia | X10-4kg*m2 | 0.19(0.23) | 0.31(0.35) |
| 制動器額定電壓 | Brake Rate Voltage | DC24V±10% | ||
| 制動器額定功率 | Brake Rate Power | W | 7.2 | |
| 制動器保持轉矩 | Brake Holding Torque | N.M | 1.3 | |
| 編碼器 | Encoder | 標準Standrad | 增量式編碼器/Incremental Encoder:2500P/R | |
| 耐熱等級 | Insulation Class | F | ||
| 環境溫度 | Ambient Temperature | 0～+40°C（不凍結/no freezing） | ||
| 環境濕度 | Ambient Humidity | 20%～80%RH(不結露/non-condensing) | ||
| 抗震性能 | Vibration | 49m/s2 | ||
| 保護方式 | Enclosure | 全封閉，自冷，IP65（除輸出軸承和連接器）Totally Enclosed,Self-cooled,IP65(Except for shaftopening and connectors) | ||
