| 產(chǎn)品參數(shù) | |||
|---|---|---|---|
| 品牌 | 倍加福 | ||
| Rated voltage | 19 ... 30 V DC | ||
| Ripple | ≤ 10 | ||
| Rated current | ≤ 37 mA | ||
| Power dissipation | ≤ 750 mW | ||
| Power consumption | ≤ 750 mW | ||
| 可售賣地 | 北京;天津;河北;山西;內(nèi)蒙古;遼寧;吉林;黑龍江;上海;江蘇;浙江;安徽;福建;江西;山東;河南;湖北;湖南;廣東;廣西;海南;重慶;四川;貴州;云南;西藏;陜西;甘肅;青海;寧夏;新疆 | ||
Data for application in connection with hazardous areas
EU-type examination certificate BASEEFA 06 ATEX 0092 X
Marking Ex-Hexagon II 3(1)G Ex ec nC [ia Ga] IIC T4 Gc , Ex-Hexagon II (1)D [Ex ia Da] IIIC , Ex-Hexagon I (M1) [Ex ia Ma] I
Input Ex ia
Voltage 10.5 V
Current 13 mA
Power 34 mW (linear characteristic)
Supply
Maximum safe voltage 253 V AC (Attention! Um is no rated voltage.)
Output
Contact loading Zone 2 : 50 V AC/2 A/cos φ > 0.75; 30 V DC/2 A resistive load
Maximum safe voltage 253 V AC (Attention! The rated voltage can be lower.)
Fault indication output
Maximum safe voltage 40 V DC (Attention! Um is no rated voltage.)
Galvanic isolation
Input/Output safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Input/power supply safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conbity
Directive 2014/34/EU EN IEC 60079-0:2018 , EN 60079-7:2015 A1:2018 , EN 60079-11:2012 , EN IEC 60079-15:2019
