3G3JZ變頻器系列 |
||||
| 額定電壓 | 保護構造 | 最大適用馬達容量 | 型號 | 額定輸出電流 |
| 單相200VAC | 盤內安裝型(IP20) | 0.2kW | 3G3JZ-AB002 | 1.6A |
| 0.4kW | 3G3JZ-AB004 | 2.5A | ||
| 0.75kW | 3G3JZ-AB075 | 4.2A | ||
| 1.5kW | 3G3JZ-AB015 | 7.5A | ||
| 2.2kW | 3G3JZ-AB022 | 11.0A | ||
| 三相200VAC | 盤內安裝型(IP20) | 0.2kW | 3G3JZ-A2002 | 1.6A |
| 0.4kW | 3G3JZ-A2004 | 2.5A | ||
| 0.75kW | 3G3JZ-A2075 | 4.2A | ||
| 1.5kW | 3G3JZ-A2015 | 7.5A | ||
| 2.2kW | 3G3JZ-A2022 | 11.0A | ||
| 3.7kW | 3G3JZ-A2037 | 17A | ||
| 三相400VAC | 盤內安裝型(IP20) | 0.4kW | 3G3JZ-A4004 | 1.5A |
| 0.75kW | 3G3JZ-A4007 | 2.5A | ||
| 1.5kW | 3G3JZ-A4015 | 4.2A | ||
| 2.2kW | 3G3JZ-A4022 | 5.5A | ||
| 3.7kW | 3G3JZ-A4037 | 8.2A | ||
